Frame
800 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat mount disc, 142x12mm thru axle
-
Fork
Domane SLR carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, carbon dropouts, 12x100mm thru axle
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).
-
Battery
Shimano BT-DN300
-
Charger
Charging cable included
-
Shifter
Shimano Ultegra R8170 Di2, 12 speed
-
Front derailleur
Shimano Ultegra R8150 Di2, braze-on, down swing
-
Rear derailleur
Shimano Ultegra R8150 Di2, 34T max cog
-
Crank
47, 50:Shimano Ultegra R8100, 50/34, 165mm length
52, 54, 56: Shimano Ultegra R8100, 50/34, 170mm length
58, 60, 62: Shimano Ultegra R8100, 50/34, 172.5mm length
-
Bottom bracket
Praxis, T47 threaded, internal bearing
-
Cassette
Shimano Ultegra R8101, 11-34, 12 speed
-
Chain
Shimano Ultegra/XT M8100, 12 speed
-
Max chainring size
1x: 48T, 2x: 52/36
-
Wheel front
Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12mm thru axle
-
Wheel rear
Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, Shimano 11/12-speed freehub, 142x12mm thru axle
-
Skewer front
Bontrager Switch thru axle, removable lever
-
Skewer rear
Bontrager Switch thru axle, removable lever
-
Tire
Bontrager Kwaremont RSL, tubeless ready, folding bead, dual compound, 320 tpi, 700x32mm
-
Tire part
Bontrager TLR sealant, 6oz
-
Max tire size
38mm without fenders, 35mm with fenders (as measured, see manual for details)
-
Saddle
Verse Short Pro, carbon rails, 145mm width
-
Seatpost (Size: 47, 50, 52, 54, 56)
KVF aero carbon seatpost, 20mm offset, 280mm length
-
Seatpost (Size: 58, 60, 62)
KVF aero carbon seatpost, 20mm offset, 320mm length
-
Handlebar
47: Bontrager Aero Pro, OCLV Carbon, 31.8mm, Di2 routing, 80mm reach, 124mm drop, 38cm width
50, 52: Bontrager Aero Pro, OCLV Carbon, 31.8mm, Di2 routing, 80mm reach, 124mm drop, 40cm width
54, 56, 58: Bontrager Aero Pro, OCLV Carbon, 31.8mm, Di2 routing, 80mm reach, 124mm drop, 42cm width
60, 62: Bontrager Aero Pro, OCLV Carbon, 31.8mm, Di2 routing, 80mm reach, 124mm drop, 44cm width
-
Handlebar tape
Trek EcoTack
-
Stem
47: Trek RCS Pro, -7 degree, 70mm length
50: Trek RCS Pro, -7 degree, 80mm length
52, 54: Trek RCS Pro, -7 degree, 90mm length
56, 58:Trek RCS Pro, -7 degree, 100mm length
60, 62: Trek RCS Pro, -7 degree, 110mm length
-
Brake
Shimano Ultegra hydraulic disc, flat mount
-
Brake rotor
Shimano CL800, centerlock, 160mm
-
Rotor size
Max brake rotor sizes: 160mm front & rear
